Marani

DPA260P is a cost-effective 2-IN/6-OUT digital speaker management system. Designed to be catered for any crossover configuration, it provides the suitable processing and control for live application use. It offers 2 analog inputs, and 6 analog outputs, managed by a powerful DSP Engine, in addition to 24 Bit AD/DA Converters. Each input channel provides a choice of EQ with a 11-band Parametric EQ, gain control, noise gate function, RMS Compressor, Internal White/Pink Noise Generator and configurable delay. Each output offers up to 5-band of parametric equalization into the crossover filters which themselves provide slopes from 6dB/Octave up to 48dB/Octave. Each output path also features peak limiter and driver alignment delay.
